Öhlins TTX GP HO 568 Shock Absorber CBR1000RR-R/SP 2020-

Öhlins TTX GP HO 568 Shock Absorber CBR1000RR-R/SP 2020-

Technical data
Length:    317mm +4/-2mm mm
Stroke:    60 mm
Rate N/mm:    110 N/mm
Position:    rear
Mounted spring:    21040-39
Spring series:    21040-xx
Packaging unit:    pieces

Standard spring: 110 N/mm

Type Code: T36PR1C1LB

T: Twin tube
36: Piston diameter (in mm)
P: Monotube high pressure gas type of shock absorber with external “piggy back” reservoir.
R1: Adjustable rebound damping. Black adjuster on TTX36 shocks / silver adjuster on TTX GP shocks.
C1: Adjustable compression damping. Gold adjuster on TTX36 / TTX GP shocks.
L: Adjustable length.
B:Integrated hydraulic spring preload adjuster. Adjuster wheel or hexagon on the adjuster.
