Öhlins STX 46 Street Shock Absorber Scrambler 1100/Special 2017-2020

Öhlins STX 46 Street Shock Absorber Scrambler 1100/Special 2017-2020

Data

Type code: S46DR1

S: monotube shock absorber

46: Piston diameter: 46 mm

D: Gas pressure monotube damper with reservoir integrated in the housing

R1: Adjustable rebound damping on monotube damper. Adjustment wheel above the end eyelet.

Technical data

Length: 304.5 mm

Stroke: 57.5 mm

Rate N/mm: 105

Position: Rear

Spring: 01092-36

Packaging unit: Single

The proven STX 46 Street from Öhlins is the perfect upgrade for sporty street bikes. This gas pressure shock absorber with separating piston and an internal gas reservoir has a main piston with a diameter of 46 mm. Depending on the version, the STX 46 is equipped with mechanical or hydraulic spring preload adjustment and adjustable rebound damping.
